Specifications

[/vc_column_text][vc_empty_space][vc_row_inner css=”.vc_custom_1636437343507{margin-right: 5% !important;margin-left: 5% !important;background-color: #f0f2f2 !important;}”][vc_column_inner width=”1/2″ css=”.vc_custom_1636511322336{padding-bottom: 15px !important;}”][vc_column_text]

Rim
Series	Gnar
Wheel Size	29er
Tire Compatibility	Tubeless
Bead Type	Hookless
Rim Depth	25mm
Inner Width	30mm
Outer Width	38mm
Rim Profile	Asymmetric
Offset	3mm
Rim Finish	UD Glossy Black

[/vc_column_text][/vc_column_inner][vc_column_inner width=”1/2″][vc_column_text]

Other
Max Tire Pressure	50psi/3.45bar
Extras	Rim Tape(Installed), Tubeless Valves(Installed)
Weight (Pair)	1150+/-30g(without tubeless valves and rim tape)
Rider Weight Limit	265lbs/120kg
Recommended Tire Sizes	2.2”-2.7”
Intended Use	Cross Country
ERD	598mm

[/vc_column_text][/vc_column_inner][/vc_row_inner][vc_row_inner css=”.vc_custom_1636437343507{margin-right: 5% !important;margin-left: 5% !important;background-color: #f0f2f2 !important;}”][vc_column_inner width=”1/2″ css=”.vc_custom_1636511322336{padding-bottom: 15px !important;}”][vc_column_text]

Hub
Front Hub Spacing	15x110mm
Rear Hub Spacing	12x148mm
Bearing	TPI Steel
Brake Compatibility	Disc (6-bolt)
Freehub Type	60T Ratchet
Freehub Compatibility	Shimano HG / SRAM XD / Shimano MS

[/vc_column_text][/vc_column_inner][vc_column_inner width=”1/2″][vc_column_text]

Spoke
Front Spoke Pattern	2X/2X(1:1）
Rear Spoke Pattern	2X/2X(1:1）
Spoke Count	20F/24R
Spoke Type	Carbon Spoke(2.2mm)
Nipple Type	Carbon Secure Lock

[/vc_column_text][/vc_column_inner][/vc_row_inner][/vc_column][/vc_row][vc_row css=”.vc_custom_1636522597176{margin-right: -5% !important;margin-left: -5% !important;background-color: #ffffff !important;}”][vc_column][vc_row_inner content_placement=”middle” css=”.vc_custom_1636625660188{margin-right: 5% !important;margin-left: 5% !important;background-color: #f0f2f2 !important;}”][vc_column_inner width=”1/2″ css=”.vc_custom_1636524634550{margin-top: -10px !important;background-color: #ffffff !important;}”][vc_single_image image=”99684″ img_size=”full” onclick=”link_image” title=”29er Gnar SL SS Rim Structure”][/vc_column_inner][vc_column_inner width=”1/2″][vc_column_text css=”.vc_custom_1773041460859{margin-right: 20px !important;margin-left: 20px !important;padding-right: 5px !important;padding-left: 5px !important;}”]

CARBON-SPOKE RIM STRUCTURE

The Gnar SL CS uses carbon-spoke rim drilling, allowing the wheel structure to be optimized for reduced weight while maintaining the strength required for off-road riding. An optimized carbon fiber layup further refines the rim structure, minimizing excess material around the spoke interface while preserving structural integrity. The combination of carbon-spoke drilling and refined material stacking results in a wheelset weight of 1150g, delivering a lightweight yet durable platform for cross-country performance.[/vc_column_text][/vc_column_inner][/vc_row_inner][/vc_column][/vc_row][vc_row css=”.vc_custom_1636436261896{margin-right: -5% !important;margin-left: -5% !important;background-color: #ffffff !important;}”][vc_column][vc_row_inner content_placement=”middle” css=”.vc_custom_1636625730552{margin-right: 5% !important;margin-left: 5% !important;background-color: #f0f2f2 !important;}”][vc_column_inner width=”1/2″][vc_single_image image=”99686″ img_size=”full” onclick=”link_image” title=”29er Gnar SL CS Freehub” css=”.vc_custom_1773044101766{margin-top: -10px !important;}”][/vc_column_inner][vc_column_inner width=”1/2″][vc_column_text css=”.vc_custom_1773125803442{margin-right: 20px !important;margin-left: 20px !important;padding-right: 5px !important;padding-left: 5px !important;}”]

RAPIDDRIVE HUB SYSTEM

The wheelset is built around the RapidDrive hub, featuring a 60-tooth ratchet system with a 6° engagement angle for quick engagement and responsive power transfer. The high-density slanted ratchet teeth provide faster pedaling response when accelerating or navigating technical trail sections. A titanium alloy freehub body ensures strong and efficient power transmission while maintaining low weight and excellent long-term durability.

Discover the Hub Sound Here[/vc_column_text][/vc_column_inner][/vc_row_inner][/vc_column][/vc_row][vc_row css=”.vc_custom_1636436261896{margin-right: -5% !important;margin-left: -5% !important;background-color: #ffffff !important;}”][vc_column][vc_row_inner content_placement=”middle” css=”.vc_custom_1636625761971{margin-right: 5% !important;margin-left: 5% !important;background-color: #f0f2f2 !important;}”][vc_column_inner width=”1/2″][vc_single_image image=”99685″ img_size=”full” onclick=”link_image” title=”29er Gnar XC Spokes” css=”.vc_custom_1773044134995{margin-top: -10px !important;}”][/vc_column_inner][vc_column_inner width=”1/2″][vc_column_text css=”.vc_custom_1773041408753{margin-right: 20px !important;margin-left: 20px !important;padding-right: 5px !important;padding-left: 5px !important;}”]

LIGHTWEIGHT SPOKE LAYOUT

With a 20 front / 24 rear spoke configuration, the wheelset reduces rotational weight while maintaining structural stability. Combined with 2.2mm Carbon Spokes, the wheel achieves an effective balance between weight savings and strength for cross-country riding.

[/vc_column_text][/vc_column_inner][/vc_row_inner][/vc_column][/vc_row][vc_row css=”.vc_custom_1636436261896{margin-right: -5% !important;margin-left: -5% !important;background-color: #ffffff !important;}”][vc_column][vc_row_inner content_placement=”middle” css=”.vc_custom_1636625761971{margin-right: 5% !important;margin-left: 5% !important;background-color: #f0f2f2 !important;}”][vc_column_inner width=”1/2″][vc_single_image image=”99693″ img_size=”full” onclick=”link_image” title=”29er Gnar SL SS” css=”.vc_custom_1773044326618{margin-top: -10px !important;}”][/vc_column_inner][vc_column_inner width=”1/2″][vc_column_text css=”.vc_custom_1773041501587{margin-right: 20px !important;margin-left: 20px !important;padding-right: 5px !important;padding-left: 5px !important;}”]

EFFICIENT CROSS-COUNTRY PERFORMANCE

The Gnar SL CS is engineered for riders who prioritize climbing efficiency and responsive handling. The lightweight structure helps reduce rotational mass, improving acceleration and climbing performance while maintaining the durability required for technical terrains.
