Specifications

[/vc_column_text][vc_empty_space][vc_row_inner css=”.vc_custom_1636437343507{margin-right: 5% !important;margin-left: 5% !important;background-color: #f0f2f2 !important;}”][vc_column_inner width=”1/2″ css=”.vc_custom_1636511322336{padding-bottom: 15px !important;}”][vc_column_text]

Rim
Series	Drive
Wheel Size	700c
Tire Compatibility	Clincher/ Tubeless
Bead Type	Hooked
Rim Depth	50mm
Inner Width	30mm
Outer Width	37mm

[/vc_column_text][/vc_column_inner][vc_column_inner width=”1/2″][vc_column_text]

Hub
Front Hub Spacing	12x100mm
Rear Hub Spacing	12x142mm
Bearing	TPI Steel
Brake Compatibility	Disc
Freehub Type	60T Ratchet
Freehub Compatibility	Shimano HG / SRAM XDR

[/vc_column_text][/vc_column_inner][/vc_row_inner][vc_row_inner css=”.vc_custom_1636437343507{margin-right: 5% !important;margin-left: 5% !important;background-color: #f0f2f2 !important;}”][vc_column_inner width=”1/2″ css=”.vc_custom_1636511322336{padding-bottom: 15px !important;}”][vc_column_text]

Spoke
Front Spoke Pattern	3X/Radial (2:1)
Rear Spoke Pattern	1X/3X (1:2)
Spoke Count	21F/24R
Spoke Type	Alpina Ultralite Aero
Nipple Type	Sapim Secure Lock

[/vc_column_text][/vc_column_inner][vc_column_inner width=”1/2″][vc_column_text]

Other
Rim Finish	Glossy Marbling Black
Extras	Rim Tape(Installed), Tubeless Valves(Installed)
Weight (Pair)	1425±30g (without tubeless valves and rim tape)
Rider Weight Limit	265lbs/120kg
Compatible Tire Sizes	700 x 40-60C
Recommended Tire Sizes	700 x 40-60C

[/vc_column_text][/vc_column_inner][/vc_row_inner][/vc_column][/vc_row][vc_row css=”.vc_custom_1636522597176{margin-right: -5% !important;margin-left: -5% !important;background-color: #ffffff !important;}”][vc_column][vc_row_inner content_placement=”middle” css=”.vc_custom_1636625660188{margin-right: 5% !important;margin-left: 5% !important;background-color: #f0f2f2 !important;}”][vc_column_inner width=”1/2″ css=”.vc_custom_1636524634550{margin-top: -10px !important;background-color: #ffffff !important;}”][vc_single_image image=”99812″ img_size=”full” onclick=”link_image” title=”DRIVE G50 SS RIM”][/vc_column_inner][vc_column_inner width=”1/2″][vc_column_text css=”.vc_custom_1773105466950{margin-right: 20px !important;margin-left: 20px !important;padding-right: 5px !important;padding-left: 5px !important;}”]

WIDE GRAVEL RIM DESIGN

The G50 SS features a wide gravel-optimized rim profile, with a 30 mm internal width and a hooked

The wide platform improves traction, cornering stability, and comfort on rough terrain, while the hooked bead enhances tire retention and safety under demanding riding conditions.

This rim profile is engineered to meet the needs of modern gravel riding, where larger tire volumes and lower pressures are commonly used to improve control and ride quality.[/vc_column_text][/vc_column_inner][/vc_row_inner][/vc_column][/vc_row][vc_row css=”.vc_custom_1636436261896{margin-right: -5% !important;margin-left: -5% !important;background-color: #ffffff !important;}”][vc_column][vc_row_inner content_placement=”middle” css=”.vc_custom_1636625761971{margin-right: 5% !important;margin-left: 5% !important;background-color: #f0f2f2 !important;}”][vc_column_inner width=”1/2″][vc_single_image image=”99811″ img_size=”full” onclick=”link_image” title=”DRIVE G50 SS Spoke” css=”.vc_custom_1773134903153{margin-top: -10px !important;}”][/vc_column_inner][vc_column_inner width=”1/2″][vc_column_text css=”.vc_custom_1773105553135{margin-right: 20px !important;margin-left: 20px !important;padding-right: 5px !important;padding-left: 5px !important;}”]

TORQUED DRIVE HUB SYSTEM

At the center of the wheelset is the Torqued Drive hub system, featuring a 60-tooth ratchet with a 6° engagement angle for fast and responsive power transfer.

The hub adopts a 2:1 spoke flange design, helping balance spoke tension and increase overall wheel stiffness. This design improves durability while maintaining efficient power transfer during hard acceleration.

A titanium alloy freehub body ensures efficient power transmission while keeping weight low. Combined with TPI steel bearings, the hub delivers smooth rolling performance and reliable long-term durability for gravel riding conditions.[/vc_column_text][/vc_column_inner][/vc_row_inner][/vc_column][/vc_row][vc_row css=”.vc_custom_1636436261896{margin-right: -5% !important;margin-left: -5% !important;background-color: #ffffff !important;}”][vc_column][vc_row_inner content_placement=”middle” css=”.vc_custom_1636625730552{margin-right: 5% !important;margin-left: 5% !important;background-color: #f0f2f2 !important;}”][vc_column_inner width=”1/2″][vc_single_image image=”99813″ img_size=”full” onclick=”link_image” title=”DRIVE G50 Steel Spoke” css=”.vc_custom_1773135015529{margin-top: -10px !important;}”][/vc_column_inner][vc_column_inner width=”1/2″][vc_column_text css=”.vc_custom_1773134756969{margin-right: 20px !important;margin-left: 20px !important;padding-right: 5px !important;padding-left: 5px !important;}”]

OPTIMIZED SPOKE CONFIGURATION

G50 SS uses high-strength Alpina Ultralite Aero steel spokes in a 21 front / 24 rear configuration, designed to achieve a balanced combination of stiffness, durability, and impact resistance.

This spoke layout enhances lateral stability for precise handling while retaining controlled compliance to absorb vibrations from rough terrain. The configuration also promotes even spoke tension distribution, contributing to long-term wheel stability during extended gravel rides and demanding surface conditions.[/vc_column_text][/vc_column_inner][/vc_row_inner][/vc_column][/vc_row][vc_row css=”.vc_custom_1636436261896{margin-right: -5% !important;margin-left: -5% !important;background-color: #ffffff !important;}”][vc_column][vc_row_inner content_placement=”middle” css=”.vc_custom_1636625782773{margin-right: 5% !important;margin-left: 5% !important;background-color: #f0f2f2 !important;}”][vc_column_inner width=”1/2″][vc_single_image image=”99786″ img_size=”full” onclick=”link_image” title=”DRIVE G45 SS Bearings” css=”.vc_custom_1773134981627{margin-top: -10px !important;}”][/vc_column_inner][vc_column_inner width=”1/2″][vc_column_text css=”.vc_custom_1773105852174{margin-right: 20px !important;margin-left: 20px !important;padding-right: 5px !important;padding-left: 5px !important;}”]

DESIGNED FOR MODERN

The Drive G50 SS is engineered around real-world gravel riding demands.

By combining a wide gravel rim profile, durable steel spoke structure, and responsive hub engagement, the wheelset provides consistent performance across long gravel rides, endurance events, and mixed terrain routes.

The design prioritizes reliability, stability, and control, ensuring riders can maintain confidence and efficiency even when the terrain becomes unpredictable.[/vc_column_text][/vc_column_inner][/vc_row_inner][/vc_column][/vc_row][vc_row css=”.vc_custom_1636435287316{margin-right: -5% !important;margin-left: -5% !important;background-color: #ffffff !important;}”][vc_column][vc_single_image image=”22720″ img_size=”full” css=”.vc_custom_1698287551482{margin-right: 5% !important;margin-left: 5% !important;}”][/vc_column][vc_column][vc_row_inner][vc_column_inner width=”1/6″][/vc_column_inner][vc_column_inner width=”2/3″][vc_column_text]
